Specifikationer |
Input Type |
DVI : DVI x 2 (one for 16 video, one for 16 audio) D-Type: DB15 x 2 (for video) ; DB9 x 2 (extension card for audio) |
Video Input(s) |
16 Cams |
Audio Input(s) |
16 Channels |
TV Output |
RCA Connector x 1 |
Recording Rate At 320 X 240 Resolution |
480 fps (NTSC), 400 fps (PAL) |
Display Rate |
480 fps (NTSC), 400 fps (PAL) |
Video Resolution - NTSC/PAL |
Full D1, Half D1, CIF |
Compression Format |
Wavelet, MPEG-4, Geo MPEG4, Geo MPEG4 (ASP), Geo H264 |
GV-NET/IO Card Support |
Yes |
GV-Hybrid DVR Card Support |
Yes |
Dimensions |
DVI: 165 (W) x 95 (H) mm D-Type: 170 (W) x 95 (H) mm
D-Type PCI Express: 212 (W) x 99 (H) mm |
Installation Guide |
DVI D-Type
PCI Express |
Note: GV-1480 is currently not compatible with VIA series and ATI series chipset motherboards. |
System Requirements |
OS Supported |
Windows 2000 / Windows XP / Windows Server 2003 / Windows Vista |
CPU |
Pentium 4-2.8C GHz, 800 MHz FSB (minimum) |
RAM |
2 x 256 MB dual DDR400 SDRAM (minimum) |
HDD |
250 GB or above (recommended) |
VGA |
ATI Radeon 9550 or above (recommended) |
DirectX |
9.0 or above |
